Mardome Trade Dome Rooflight Manual Hinged Vent & Winding Rod to Builders Kerb

SKU: MDTMHBK1
Regular price £398.17 inc. VAT (£331.81 EXC. VAT )

Mardome polycarbonate dome rooflights are manufactured from high quality polycarbonate with a 100mm high PVC DF kerb suitable for fitting to a builders timber kerb. They are designed to make optimum use of natural light with a generous glazing area they offer up to 33% more daylight and are offered in a wide range of sizes. They are opened manually by an operating pole (supplied free of charge) which is used to wind the rooflight open and closed by hand.

Mardome Trade polycarbonate dome with 100mm high white PVC DF kerb and manual hinged ventilation. Unit designed to fit to a builders timber kerb.

  • 100mm high white PVC DF kerb
  • Free of charge 1m winding rod
  • Direct fit to builders timber kerb
  • Security fixings (supplied) provide a high level of resistance to forced entry

The above unit is supplied with a 100mm white PVC DF kerb to allow the unit to fit directly to a reccomended 75mm wide builders kerb. The sizes above are external weathered kerb sizes, clearlight size will be less 150mm.

Free delivery to mainland UK addresses in just 2 - 3 working days on the below sizes

450mm x 450mm
600mm x 600mm
750mm x 750mm
900mm x 600mm
900mm x 750mm
900mm x 900mm
1050mm x 600mm
1050mm x 750mm
1050mm x 1050mm
1200mm x 600mm
1200mm x 900mm
1200mm x 1200mm
1350mm x 1050mm
1350mm x 1350mm
1500mm x 1050mm
1500mm x 1500mm
1800mm x 900mm
1800mm x 1200mm
1800mm x 1800mm

All other sizes available in 7 - 10 working days

Units designed to fit to a builders timber kerb.  Dimensions above are the overall weathered kerb size.

Acceptable tolerance:
Opening / vented domes = dome size +40/-20mm

Product Image

Manufactured from white uPVC and clear or diffused polycarbonate which offers:

- UV protected polycarbonate for all skins.

- Hinged on the long dimension

- 100mm high Vertical White PVC DF kerb fot fitting direct to builders kerb

- Security fixings (supplied) provide a high level of resistance to forced entry.

- Impact tested under current BS EN 1873 to pass classification of SB 1200.

- Complies with BS 476 and BS EN 13501-1 fire ratings.

- Double skin U value between 1.54 and 2.09 W/m²;K

- Triple skin U value between 1.25 and 1.51 W/m²;K

- All pictures/drawings are for illustration purpose only. Actual product may vary due to product enhancement.

Please click for cleaning & maintenance instructions

For full technical information please click here

Product Image

For installation details please click here

For internal plasterboard detail please click here

Rooflights & Skylights polycarbonate domes are manufactured from enhanced polycarbonate that will not show excessive changes in colour or loss of light transmission, nor will they break due to loss of impact strength, due to weathering, within 10 years from the date of sale.
